GKN Aerospace Cuts Assembly Tool Production Time with Stratasys Additive Manufacturing

  • Time cut from several weeks to a few hours using Stratasys Production 3D Printer
  • GKN Aerospace is producing complex tools that were uneconomical or impossible to make without additive manufacturing

MINNEAPOLIS & REHOVOT, Israel–September 05, 2018 — (BUSINESS WIRE) — Stratasys (Nasdaq:SSYS) today announced that GKN Aerospace is improving production times and removing design constraints for multiple tooling applications since integrating additive manufacturing at its Filton manufacturing site in the UK.

GKN serves over 90 percent of the world’s aircraft and engine manufacturers with aerostructures, engine systems and technologies.

According to Tim Hope, Additive Manufacturing Center Manager, at GKN Aerospace, the company decided to invest in the Stratasys F900 Production 3D Printer in a bid to cut lead times for production-line tools, and to create complex parts, impossible to make with traditional manufacturing methods.

“Since integrating the F900, we have dramatically reduced production-line downtime for certain teams and are enjoying a new found freedom to design complex tools,” he says.

Traditionally, the lead-time required to produce a metal or plastic replacement tool is several weeks. Now, with the ability to use an in-house production 3D printer to do the same job, the replacement burden has been removed and the responsiveness to manufacturing requirements improved.

“We can now cost-effectively produce tools for our operators within three hours,” Hope explains. “This saves critical production time, and by printing in engineering-grade thermoplastics, we can produce 3D printed tools with repeatable, predictable quality every time. All while matching the quality of a traditionally-produced tool, and reducing the costs and concessions compared to equivalent metallic tooling.”

Produced on the Stratasys F900 Production 3D Printer, this small tool enables GKN to quickly cut new bungs to the correct size and enables several parts to be processed at once (Photo: Business Wire)

Produced on the Stratasys F900 Production 3D Printer, this small tool enables GKN to quickly cut new bungs to the correct size and enables several parts to be processed at once (Photo: Business Wire)

While GKN Aerospace is using a standard thermoplastic today, it is experimenting with Stratasys’ high-strength, heat-resistant ULTEM™ 1010 Resin material for these applications.

Customized, complex tools that were previously impossible to make
In addition, GKN Aerospace is reporting unprecedented levels of design freedom since investing in the Stratasys F900 into its operations.

“One of the key benefits of additive manufacturing is the creative freedom this technology affords users,” explains Hope. “The F900 offers the largest build-size of any FDM 3D printer enabling us to rapidly produce tools to meet any requirements. Most notably, complex geometries and cavities that would otherwise be problematic are now practical with the F900. We’re utilising it to design, and 3D print, previously inconceivable tools that enable us to manufacture complex parts that are uneconomical or just physically impossible by other methods.”

In addition to design freedom benefits, GKN Aerospace has also seen a 40 percent decrease in material waste.

3D printed bespoke fixtures that are uneconomical or physically impossible to create by any other manufacturing methods (Photo: Business Wire)

3D printed bespoke fixtures that are uneconomical or physically impossible to create by any other manufacturing methods (Photo: Business Wire)

To the future
Hope anticipates a greater move towards the use of FDM additive manufacturing to produce high-value, flight-critical, end-use composite parts.

He says. “GKN Aerospace’s product range is vast, and we see large-scale FDM and carbon-reinforced parts as the future of additive manufacturing in aerospace. By using Stratasys additive manufacturing for tooling, we are harnessing a machine that offers us the freedom to produce unique and complex tools of any size, with the build quality to match any manufacturing requirement. All while simultaneously preparing ourselves for the future.”

Stratasys is a global leader in additive manufacturing or 3D printing technology and is the manufacturer of FDM® and PolyJet™ 3D Printers. The company’s technologies are used to create prototypes, manufacturing tools, and production parts for industries, including aerospace, automotive, healthcare, consumer products and education. For 30 years, Stratasys products have helped manufacturers reduce product-development time, cost, and time-to-market, as well as reduce or eliminate tooling costs and improve product quality. The Stratasys 3D printing ecosystem of solutions and expertise includes: 3D printers, materials, software, expert services, and on-demand parts production. Online at: www.stratasys.com, http://blog.stratasys.com and LinkedIn.

Stratasys, FDM, and Fortus are registered trademarks, and the Stratasys signet is a trademark of Stratasys Ltd. and/or its subsidiaries or affiliates. ULTEM 1010 Resin is a registered trademark of SABIC or its affiliates or subsidiaries. All other trademarks are the property of their respective owners.
